Rainer Arca Aix adalah server AI kelas enterprise 6U yang dirancang untuk kebutuhan komputasi berat seperti Artificial Intelligence, HPC, Large Language Model (LLM) Development, dan Big Data Analytics.
Dengan dukungan multi-GPU performa tinggi dan prosesor generasi terbaru, Arca Aix menghadirkan kekuatan komputasi maksimal dalam satu sistem yang tangguh dan scalable.
Menyokong hingga 8 GPU aktif atau pasif slot ganda per sistem, dengan dukungan NVIDIA NVLink® Bridge untuk bandwidth interkoneksi tinggi — memberikan efisiensi pelatihan AI dan akselerasi inferensi yang superior.
Ditenagai oleh prosesor Intel® Xeon® Generasi ke-4 yang mendukung beban kerja intensif di lingkungan cloud, edge, dan jaringan — siap untuk menjalankan workload AI, HPC, dan big data secara simultan.
Dirancang dengan terowongan aliran udara CPU dan GPU yang terpisah untuk pendinginan optimal serta mendukung hingga empat catu daya redundan Titanium 3000W untuk keandalan operasional 24/7.
Menyediakan solusi pendinginan yang fleksibel untuk mendukung TDP CPU/GPU tinggi, termasuk dukungan pendinginan cairan dan udara sesuai kebutuhan beban kerja berat dan kompleks.
Hingga 8 drive Tri-Mode (NVMe/SATA/SAS) di bagian depan dan 11 slot ekspansi PCIe 5.0 — memberikan bandwidth tinggi dan fleksibilitas integrasi perangkat tambahan seperti DPU, NIC, atau akselerator.
Mendukung modul OCP 3.0 dan slot PCIe 5.0 untuk NIC berkecepatan tinggi di bagian belakang, memfasilitasi konektivitas skala besar dan deployment jaringan AI fabric.
High Performance GPU Servers for AI Training/Inference Workloads.
Intel® Xeon® 6700P-series, 6500P-series, and 6700E-series processors
2 x RJ45 LAN (1GbE)
NVIDIA® ConnectX®-8 SuperNIC: 8 OSFP (800Gb/s)
12 Hot-swap 2.5" NVMe (PCIe5.0 x4) drive bays
Up to 4TB DDR5 ECC RDIMM Memory
NVIDIA® HGX™ B300 NVL8
Cloud Services Providers
Neoclouds
Enterprise
Gevornment
High Performance GPU Servers for AI Training/Inference Workloads.
Dual AMD EPYC™ 9005/9004 (with AMD 3D V-Cache™ Technology)
2 x RJ45 LAN (1GbE)
10G/100G/200G Network Connections (Optional)
12 Hot-swap 2.5" NVMe (PCIe5.0 x4) drive bays
Up to 4TB DDR5 ECC RDIMM Memory
AMD Instinct™ MI300X 8-GPU with Infinity Fabric™ Links
Cloud Services Providers
Neoclouds
Enterprise
Gevornment
High Performance GPU Servers for AI Training/Inference Workloads.
Dual Intel® 5th Gen Xeon® Scalable or AMD EPYC 9004/9005 Processors
10G/100G/400G LAN Connectivity
12 Hot-swap 3.5”/2.5” NVME/SAS/SATA Drive Bays
Up to 6TB DDR5 ECC RDIMM Memory
Up to 8x Nvidia RTX Pro Blackwell GPU
Cloud Services Providers
Neoclouds
Enterprise
Gevornment
High Performance Servers for AI Inference at the Edge.
Single Intel Xeon 6300/ 5th Gen Xeon Scalable Processor
Single AMD EPYC 4005/Ryzen 9000 Processor
10G LAN Connectivity
Up to 4 x 3.5”/2.5” HDD bays
Up to 512GB DDR5 ECC UDIMM/RDIMM Memory
Up to 4 Nvidia/AMD/Intel GPU Support.
Enterprise
Telco
Government
Education
Manufacturing
BFSI
.avif)
.avif)
.avif)
.avif)
| Processor | Support up to 2 × 4th & 5th Gen Intel®Xeon® Scalable Processors (Eagle Stream), up to 64 cores and TDP 385W each, support HBM |
|
|---|---|---|
| Memory | Support up to 32 × DDR5 DIMMs, up to 5600MT/s, support RDIMM, up to 8TB capacity Support CXL 1.1* |
|
| Storage |
Integrated 6Gb/s SATA controller；Support 12Gb/s SAS HBA / RAID controller Support up to 12 × 3.5ˮHDDs Support 2 × M.2 2280/22110 SATA or 1 × M.2 2280/22110 NVMe SSD optional |
|
| PCIe Expansion |
Up to 13 × standard PCIe expansion slots Up to 10 × standard PCIe x16 expansion slots Support 1 × OCP3.0 slot |
Up to 27 × standard PCIe expansion slots Up to 27 × standard PCIe x16 expansion slots SSupport 1 × OCP3.0 slot (1 × standard PCIe slots optional) |
| Management | Integrated BMC management chip (AST2600), support IPMI2.0, Redfish, SOL, KVM, Virtual media, etc | |
| Network |
Support 1 × OCP3.0 network card 1/10/25/50/100/200/400GE PCIe standard network card optional |
|
| Security | Support chassis intrusion detection, Support Intel PFR3.0 & SGX2.0, support TCM / TPM security modul | |
| Fan |
Lower 2U fan panel support 8 × 8056 / 8038 fan, N+1 hot swappable redundancy Middle fan panel support × 8056 / 8038 fan, N+1 hot-swappable redundancy |
|
| Power |
Support 8 × CRPS hot-swappable power module, support N+N/N+1 redundancy 2000W/2400W/2700W/3200W Platinum or Titanium power module optional |
|
| Environment | Operating temperature: 0℃～35℃ (Affected by configurations) | |
| Dimension |
6U standard rack server 263.7mm H × 447mm W × 898mm D (Without security panel) |
